FDMM001GPE-1004 - Flexxon

FDMM001GPE-1004
microSD Card FxPro I High IOPS pSLC 1GB Diamond
The FxPro Secure Digital (microSD) card version 5.0 pSLC 1GB Diamond is fully compliant with the specification released by the microSD Card Association. It can alternate communication protocol between the microSD mode and SPI mode.

FLEXXON FxPro I High IOPS microSD card provides high performance, good reliability, wide compatibility and industrial operating temperature flexibility.
- Advanced Flash Management: Static and Dynamic Wear Leveling; Bad Block
Management; SMART Function; Auto-Read Refresh
- Support SD 5.0
- Support SD SPI mode
- Designed for read-only and read/write cards
- Copyrights Protection Mechanism
- CPRM (Content Protection for Recordable Media) of SD Card supported. (Optional)
- Card removal during read operation will never harm the content
- Password Protection of cards (option)
- Write Protect feature using mechanical switch
- Support Power Loss Protection Algorithm (optional)
- +4KV/-4KV ESD protection in contact pads
- RoHS Compliant
Manufacturer:
Productgroup: microSD CardsmicroSD Cards
Part Number: FDMM001GPE-1004
Series: FxPro I
State: 🟢 Active
Note article Merkzettel Request article Anfrage


Technical data

Series: FxPro I HighIOPS
Form Factor: microSD
Memory Type: pSLC
Interface: SD 5.1
Capacity: 1GB
Write Performance : 20 MB/s
Read Performance : 20 MB/s
Operating Voltage : 2,7 - 3,6 V
MTBF: 3000000
Shock Resistance: 1500G/0.5ms
Vibration Resistance: 80Hz ~ 2000Hz/20G
Industrie: Yes
Medical: No
Power Loss Protection: No
PINs: 8
  Length: 15 mm
  Width: 11 mm
  Heigth: 1 mm
  Min. operating temperature: -40 °C
  Max. operating temperature: 85 °C

Hint: current revision of the supplier datasheet is applicable
