Highpower LEDs
High-power LEDs are designed for forward currents of 150 mA and above and deliver high light output. They are characterized by defined thermal characteristics (Rth), good heat dissipation, and a long service life. For thermal management, we provide support in heat sink design, derating, and the selection of the appropriate high-power LED.
|
|
|||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Bridgelux | COB_E22 | Natural White | – | 4000 K | 80 | 2057874 mcd | 6465 lm | 179 lm/W | 36.18 W | 33.5 V | 1080 mA | 2880 mA | 120 ° | – | No | 28 mm | 28 mm | 1.4 mm | -40 °C | 105 °C | COB | 0.01 g | |
| Bridgelux | COB_Vero29 | Warm White | – | 1750 K | 80 | 2740966 mcd | 8611 lm | 92 lm/W | 93.6 W | 52 V | 1800 mA | 3600 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 29 SE | Warm White | – | 1750 K | 80 | 2734282 mcd | 8590 lm | 92 lm/W | 93.6 W | 52 V | 1800 mA | 3600 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero29 | Warm White | – | 1750 K | 80 | 3475307 mcd | 10918 lm | 92 lm/W | 118.67 W | 69.4 V | 1710 mA | 3420 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 29 SE | Warm White | – | 1750 K | 80 | 3466713 mcd | 10891 lm | 92 lm/W | 118.67 W | 69.4 V | 1710 mA | 3420 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero29 | Warm White | – | 1750 K | 80 | 2312203 mcd | 7264 lm | 92 lm/W | 78.96 W | 37.6 V | 2100 mA | 4200 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 29 SE | Warm White | – | 1750 K | 80 | 2306473 mcd | 7246 lm | 92 lm/W | 78.96 W | 37.6 V | 2100 mA | 4200 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero18 | Warm White | – | 1750 K | 80 | 917051 mcd | 2881 lm | 92 lm/W | 31.32 W | 34.8 V | 900 mA | 1800 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 18 SE | Warm White | – | 1750 K | 80 | 905273 mcd | 2844 lm | 91 lm/W | 31.32 W | 34.8 V | 900 mA | 1800 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero18 | Warm White | – | 1750 K | 80 | 1153555 mcd | 3624 lm | 89 lm/W | 40.72 W | 34.8 V | 1170 mA | 2340 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 18 SE | Warm White | – | 1750 K | 80 | 1176792 mcd | 3697 lm | 91 lm/W | 40.72 W | 34.8 V | 1170 mA | 2340 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero18 | Warm White | – | 1750 K | 80 | 862620 mcd | 2710 lm | 89 lm/W | 30.45 W | 29 V | 1050 mA | 2100 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 18 SE | Warm White | – | 1750 K | 80 | 880127 mcd | 2765 lm | 91 lm/W | 30.45 W | 29 V | 1050 mA | 2100 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero10 | Warm White | – | 2000 K | 65 | 455501 mcd | 1431 lm | 152 lm/W | 9.4 W | 34.8 V | 270 mA | 540 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 10 SE | Warm White | – | 2000 K | 65 | 442769 mcd | 1391 lm | 148 lm/W | 9.4 W | 34.8 V | 270 mA | 540 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero10 | Warm White | – | 2000 K | 65 | 441178 mcd | 1386 lm | 152 lm/W | 9.1 W | 26 V | 350 mA | 700 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 10 SE | Warm White | – | 2000 K | 65 | 428763 mcd | 1347 lm | 148 lm/W | 9.1 W | 26 V | 350 mA | 700 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero29 | Warm White | – | 2000 K | 65 | 5930750 mcd | 18632 lm | 157 lm/W | 118.67 W | 69.4 V | 1710 mA | 3420 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 29 SE | Warm White | – | 2000 K | 65 | 5915789 mcd | 18585 lm | 157 lm/W | 118.67 W | 69.4 V | 1710 mA | 3420 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero29 | Warm White | – | 2000 K | 95 | 3946088 mcd | 12397 lm | 157 lm/W | 78.96 W | 37.6 V | 2100 mA | 4200 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 29 SE | Warm White | – | 2000 K | 65 | 3936220 mcd | 12366 lm | 157 lm/W | 78.96 W | 37.6 V | 2100 mA | 4200 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero18 | Warm White | – | 2000 K | 65 | 2034637 mcd | 6392 lm | 157 lm/W | 40.72 W | 34.8 V | 1170 mA | 2340 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 18 SE | Warm White | – | 2000 K | 65 | 2008217 mcd | 6309 lm | 155 lm/W | 40.72 W | 34.8 V | 1170 mA | 2340 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero18 | Warm White | – | 2000 K | 65 | 1521840 mcd | 4781 lm | 157 lm/W | 30.45 W | 29 V | 1050 mA | 2100 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 18 SE | Warm White | – | 2000 K | 65 | 1502104 mcd | 4719 lm | 155 lm/W | 30.45 W | 29 V | 1050 mA | 2100 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero29 | Warm White | – | 2500 K | 80 | 4558516 mcd | 14321 lm | 153 lm/W | 93.6 W | 52 V | 1800 mA | 3600 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 29 SE | Warm White | – | 2500 K | 80 | 4547057 mcd | 14285 lm | 153 lm/W | 93.6 W | 52 V | 1800 mA | 3600 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero29 | Warm White | – | 2500 K | 80 | 5779553 mcd | 18157 lm | 153 lm/W | 118.67 W | 69.4 V | 1710 mA | 3420 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 29 SE | Warm White | – | 2500 K | 80 | 5765229 mcd | 18112 lm | 153 lm/W | 118.67 W | 69.4 V | 1710 mA | 3420 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero29 | Warm White | – | 2500 K | 80 | 3845502 mcd | 12081 lm | 153 lm/W | 78.96 W | 37.6 V | 2100 mA | 4200 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 29 SE | Warm White | – | 2500 K | 80 | 3835952 mcd | 12051 lm | 153 lm/W | 78.96 W | 37.6 V | 2100 mA | 4200 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero18 | Warm White | – | 2500 K | 80 | 1525341 mcd | 4792 lm | 153 lm/W | 31.32 W | 34.8 V | 900 mA | 1800 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 18 SE | Warm White | – | 2500 K | 80 | 1505606 mcd | 4730 lm | 151 lm/W | 31.32 W | 34.8 V | 900 mA | 1800 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero18 | Warm White | – | 2500 K | 80 | 1983071 mcd | 6230 lm | 153 lm/W | 40.72 W | 34.8 V | 1170 mA | 2340 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 18 SE | Warm White | – | 2500 K | 80 | 1957287 mcd | 6149 lm | 151 lm/W | 40.72 W | 34.8 V | 1170 mA | 2340 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero18 | Warm White | – | 2500 K | 80 | 1483006 mcd | 4659 lm | 153 lm/W | 30.45 W | 29 V | 1050 mA | 2100 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 18 SE | Warm White | – | 2500 K | 80 | 1463589 mcd | 4598 lm | 151 lm/W | 30.45 W | 29 V | 1050 mA | 2100 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 18 SE | Warm White | – | 2500 K | 90 | 1396744 mcd | 4388 lm | 181 lm/W | 24.22 W | 34.6 V | 700 mA | – | 120 ° | – | No | 35 mm | 35 mm | 3.6 mm | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero10 | Warm White | – | 2700 K | 80 | 464096 mcd | 1458 lm | 155 lm/W | 9.4 W | 34.8 V | 270 mA | 540 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 10 SE | Warm White | – | 2700 K | 80 | 451045 mcd | 1417 lm | 151 lm/W | 9.4 W | 34.8 V | 270 mA | 540 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero10 | Warm White | – | 2700 K | 80 | 464096 mcd | 1458 lm | 155 lm/W | 9.4 W | 34.8 V | 270 mA | 540 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 10 SE | Warm White | – | 2700 K | 80 | 451045 mcd | 1417 lm | 151 lm/W | 9.4 W | 34.8 V | 270 mA | 540 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero10 | Warm White | – | 2700 K | 80 | 618794 mcd | 1944 lm | 155 lm/W | 12.53 W | 34.8 V | 360 mA | 720 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 10 SE | Warm White | – | 2700 K | 80 | 601606 mcd | 1890 lm | 151 lm/W | 12.53 W | 34.8 V | 360 mA | 720 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero10 | Warm White | – | 2700 K | 80 | 618794 mcd | 1944 lm | 155 lm/W | 12.53 W | 34.8 V | 360 mA | 720 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 10 SE | Warm White | – | 2700 K | 80 | 601606 mcd | 1890 lm | 151 lm/W | 12.53 W | 34.8 V | 360 mA | 720 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero10 | Warm White | – | 2700 K | 80 | 449454 mcd | 1412 lm | 155 lm/W | 9.1 W | 26 V | 350 mA | 700 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g | |
| Bridgelux | COB_Vero 10 SE | Warm White | – | 2700 K | 80 | 437039 mcd | 1373 lm | 151 lm/W | 9.1 W | 26 V | 350 mA | 700 mA | 120 ° | – | No | – | – | – | -40 °C | 105 °C | – | 0.01 g |
