µSSD
µSSD or micro SSD combines controller and NAND flash in a BGA package for direct soldering onto the PCB. SATA III or NVMe PCIe interfaces are available. These compact storage devices are suitable for embedded systems, industrial computers and space-constrained designs requiring performance, robustness and small footprint.
|
|
|||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Flexxon | RAPIX | uSSD | 3D TLC | NVMe PCIe Gen3 ×4 | 120 GB | 1180 MB/s | 1730 MB/s | 3.3 V | 1000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | No | 11.5 mm | 13 mm | 1.35 mm | – | 70 °C | 0.01 g | |
| Flexxon | RAPIX | uSSD | 3D TLC | NVMe PCIe Gen3 ×4 | 128 GB | 600 MB/s | 1600 MB/s | 3.3 V | 1000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | No | 11.5 mm | 13 mm | 1.35 mm | – | 70 °C | 0.01 g | |
| Flexxon | RAPIX | uSSD | 3D TLC | NVMe PCIe Gen3 ×4 | 240 GB | 1180 MB/s | 1730 MB/s | 3.3 V | 1000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | No | 11.5 mm | 13 mm | 1.35 mm | – | 70 °C | 0.01 g | |
| Flexxon | RAPIX | uSSD | 3D TLC | NVMe PCIe Gen3 ×4 | 256 GB | 1180 MB/s | 1730 MB/s | 3.3 V | 1000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | No | 11.5 mm | 13 mm | 1.35 mm | – | 70 °C | 0.01 g | |
| Flexxon | RAPIX | uSSD | 3D TLC | NVMe PCIe Gen3 ×4 | 480 GB | 1180 MB/s | 1730 MB/s | 3.3 V | 1000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | No | 11.5 mm | 13 mm | 1.35 mm | – | 70 °C | 0.01 g | |
| Flexxon | RAPIX | uSSD | 3D TLC | NVMe PCIe Gen3 ×4 | 512 GB | 1180 MB/s | 1730 MB/s | 3.3 V | 1000000 | 1500G/0.5ms | 80Hz ~ 2000Hz/20G | No | 11.5 mm | 13 mm | 1.35 mm | – | 70 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 4 GB | 50 MB/s | 160 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 4 GB | 50 MB/s | 160 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -25 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 8 GB | 100 MB/s | 165 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 8 GB | 100 MB/s | 165 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -25 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 16 GB | 90 MB/s | 320 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 16 GB | 90 MB/s | 320 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -25 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | 3D TLC | SATA III 6Gbps | 30 GB | 75 MB/s | 290 MB/s | 3,3 | 1,8 V | 2000000 | – | – | No | 16 mm | 20 mm | 1.57 mm | – | 70 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 30 GB | 160 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 30 GB | 160 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -25 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | 3D TLC | SATA III 6Gbps | 32 GB | 75 MB/s | 290 MB/s | 3,3 | 1,8 V | 2000000 | – | – | No | 16 mm | 20 mm | 1.57 mm | – | 70 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 32 GB | 160 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 32 GB | 160 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -25 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | 3D TLC | SATA III 6Gbps | 60 GB | 250 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | No | 16 mm | 20 mm | 1.57 mm | – | 70 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 60 GB | 345 MB/s | 560 MB/s | 3,3 | 1,8 V | 2000000 | – | – | No | 16 mm | 20 mm | 1.57 mm | – | 70 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 60 GB | 320 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 60 GB | 320 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -25 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | 3D TLC | SATA III 6Gbps | 64 GB | 250 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | No | 16 mm | 20 mm | 1.57 mm | – | 70 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 64 GB | 345 MB/s | 560 MB/s | 3,3 | 1,8 V | 2000000 | – | – | No | 16 mm | 20 mm | 1.57 mm | – | 70 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 64 GB | 320 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 64 GB | 320 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -25 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | 3D TLC | SATA III 6Gbps | 120 GB | 450 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | No | 16 mm | 20 mm | 1.57 mm | – | 70 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 120 GB | 465 MB/s | 560 MB/s | 3,3 | 1,8 V | 2000000 | – | – | No | 16 mm | 20 mm | 1.57 mm | – | 70 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 120 GB | 460 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 120 GB | 460 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -25 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | 3D TLC | SATA III 6Gbps | 128 GB | 450 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | No | 16 mm | 20 mm | 1.57 mm | – | 70 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 128 GB | 465 MB/s | 560 MB/s | 3,3 | 1,8 V | 2000000 | – | – | No | 16 mm | 20 mm | 1.57 mm | – | 70 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 128 GB | 460 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -40 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | MLC | SATA III 6Gbps | 128 GB | 460 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | Yes | 16 mm | 20 mm | 1.57 mm | -25 °C | 85 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | 3D TLC | SATA III 6Gbps | 240 GB | 480 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | No | 16 mm | 20 mm | 1.57 mm | – | 70 °C | 0.01 g | |
| Flexxon | XTREME | uSSD | 3D TLC | SATA III 6Gbps | 256 GB | 480 MB/s | 550 MB/s | 3,3 | 1,8 V | 2000000 | – | – | No | 16 mm | 20 mm | 1.57 mm | – | 70 °C | 0.01 g |
