TINA-Series from LEDiL Oy

With the TINA series, LEDiL Oy offers a variety of LED Lenses in different designs. Please contact us if a component is not listed or if you are looking for an alternative or need a customized solution.
Filter  (40/40 Product)
Sorting
View
3%%A
3%%E
  • Manufacturer
  • LED Series
       -

  • Beam type
  • Beam angle [°]
       -

  • Type + Color of holder
  • Plug-in depth [mm]
       -

  • Length [mm]
       -

  • Width [mm]
       -

  • Heigth [mm]
       -

  • Min. operating temperature [°C]
       -

  • Max. operating temperature [°C]
       -

2%%A
2%%E
Reset all filters [x]
Sorting
NMO-SOLDER-CLIP-A
NMO-SOLDER-CLIP-A
LEDiL Oy
Clip | Metall
Datasheet:NMO-SOLDER-CLIP-A PDF
Manufacturer LEDiL Oy
Type: Lense
LED Series: 3535
Beam type: Narrow
Beam angle: 14 °
Model: 1-fach
Type + Color of holder: Lens Black
Plug-in depth: -
Length: 5 mm
Width: 4 mm
Heigth: 5 mm
Min. operating temperature: -40 °C
Max. operating temperature: 90 °C
Models: -
Merkzettel DETAILS Details
Request Anfrage
NMO-TINA2-D
NMO-TINA2-D
LEDiL Oy
LED-Linse/Halter | 1-fach | PMMA
Datasheet:NMO-TINA2-D PDF
Manufacturer LEDiL Oy
Type: Lense
LED Series: 3535
Beam type: Narrow
Beam angle: 17 °
Model: 1-fach
Type + Color of holder: Lens Black
Plug-in depth: -
Length: 16.1 mm
Width: 16.1 mm
Heigth: 9.7 mm
Min. operating temperature: -40 °C
Max. operating temperature: 80 °C
Models: -
Merkzettel DETAILS Details
Request Anfrage
NMO-TINA2-M(CA11017)
NMO-TINA2-M(CA11017)
LEDiL Oy
LED-Linse/Halter | 1-fach | PMMA
Datasheet:NMO-TINA2-M(CA11017) PDF
Manufacturer LEDiL Oy
Type: Lense
LED Series: 3535
Beam type: Medium
Beam angle: 29 °
Model: 1-fach
Type + Color of holder: Lens Black
Plug-in depth: -
Length: 16.1 mm
Width: 16.1 mm
Heigth: 9.7 mm
Min. operating temperature: -40 °C
Max. operating temperature: 80 °C
Models: -
Merkzettel DETAILS Details
Request Anfrage
NMO-TINA2-O(CA11052)
NMO-TINA2-O(CA11052)
LEDiL Oy
LED-Linse/Halter | 1-fach | PMMA
Datasheet:NMO-TINA2-O(CA11052) PDF
Manufacturer LEDiL Oy
Type: Lense
LED Series: 3535
Beam type: Elliptical
Beam angle: 35 | 12 °
Model: 1-fach
Type + Color of holder: Lens Black
Plug-in depth: -
Length: 16.1 mm
Width: 16.1 mm
Heigth: 9.7 mm
Min. operating temperature: -40 °C
Max. operating temperature: 80 °C
Models: -
Merkzettel DETAILS Details
Request Anfrage
NMO-TINA2-RS(CA11016)
NMO-TINA2-RS(CA11016)
LEDiL Oy
LED-Linse/Halter | 1-fach | PMMA
Datasheet:NMO-TINA2-RS(CA11016) PDF
Manufacturer LEDiL Oy
Type: Lense
LED Series: 3535
Beam type: Narrow
Beam angle: 12 °
Model: 1-fach
Type + Color of holder: Lens Black
Plug-in depth: -
Length: 16.1 mm
Width: 16.1 mm
Heigth: 9.7 mm
Min. operating temperature: -40 °C
Max. operating temperature: 80 °C
Models: -
Merkzettel DETAILS Details
Request Anfrage
NMO-TINA2-RS(CA12374)
NMO-TINA2-RS(CA12374)
LEDiL Oy
LED-Linse | 1-fach | PMMA
Datasheet:NMO-TINA2-RS(CA12374) PDF
Manufacturer LEDiL Oy
Type: Lense
LED Series: 3535
Beam type: Narrow
Beam angle: 16 °
Model: 1-fach
Type + Color of holder: -
Plug-in depth: -
Length: -
Width: -
Heigth: -
Min. operating temperature: -40 °C
Max. operating temperature: 80 °C
Models: -
Merkzettel DETAILS Details
Request Anfrage
NMO-TINA2-W
NMO-TINA2-W
LEDiL Oy
LED-Linse/Halter | 1-fach | PMMA
Datasheet:NMO-TINA2-W PDF
Manufacturer LEDiL Oy
Type: Lense
LED Series: 3535
Beam type: Wide
Beam angle: 40 °
Model: 1-fach
Type + Color of holder: Lens Black
Plug-in depth: -
Length: 16.1 mm
Width: 16.1 mm
Heigth: 9.7 mm
Min. operating temperature: -40 °C
Max. operating temperature: 80 °C
Models: -
Merkzettel DETAILS Details
Request Anfrage
NMO-TINA2-W_CA12378
NMO-TINA2-W_CA12378
LEDiL Oy
LED-Linse | 1-fach | PMMA
Datasheet:NMO-TINA2-W_CA12378 PDF
Manufacturer LEDiL Oy
Type: Lense
LED Series: -
Beam type: Wide
Beam angle: 42 °
Model: 1-fach
Type + Color of holder: Lens Black
Plug-in depth: -
Length: 16 mm
Width: 16 mm
Heigth: 9 mm
Min. operating temperature: -40 °C
Max. operating temperature: 80 °C
Models: -
Merkzettel DETAILS Details
Request Anfrage
NMO-TINA3-OO
NMO-TINA3-OO
LEDiL Oy
LED-Linse/Halter | 1-fach | PMMA
Datasheet:NMO-TINA3-OO PDF
Manufacturer LEDiL Oy
Type: Lense
LED Series: 3535
Beam type: Elliptical
Beam angle: 54 | 42 °
Model: 1-fach
Type + Color of holder: Lens White
Plug-in depth: 0,8 mm
Length: 16.3 mm
Width: 16.3 mm
Heigth: 6.9 mm
Min. operating temperature: -40 °C
Max. operating temperature: 80 °C
Models: -
Merkzettel DETAILS Details
Request Anfrage
NMO-TINA3-OO_CA12429
NMO-TINA3-OO_CA12429
LEDiL Oy
Linse/Halter | 1-fach | PMMA
Datasheet:NMO-TINA3-OO_CA12429 PDF
Manufacturer LEDiL Oy
Type: Lense
LED Series: 3030 | 3528 | 3535
Beam type: Elliptical
Beam angle: 60 | 40 °
Model: 1-fach
Type + Color of holder: Lens White
Plug-in depth: 0,8 mm
Length: 16.1 mm
Width: 16.1 mm
Heigth: 6.9 mm
Min. operating temperature: -40 °C
Max. operating temperature: 80 °C
Models: -
Merkzettel DETAILS Details
Request Anfrage
NMO-TINA3-S
NMO-TINA3-S
LEDiL Oy
LED-Linse/Halter | 1-fach | PMMA
Datasheet:NMO-TINA3-S PDF
Manufacturer LEDiL Oy
Type: Lense
LED Series: 3535
Beam type: Narrow
Beam angle: 6 °
Model: 1-fach
Type + Color of holder: Lens White
Plug-in depth: 0,8 mm
Length: 16.1 mm
Width: 16.1 mm
Heigth: 11.4 mm
Min. operating temperature: -40 °C
Max. operating temperature: 80 °C
Models: -
Merkzettel DETAILS Details
Request Anfrage
NMO-TINA3-W
NMO-TINA3-W
LEDiL Oy
LED-Linse | 1-fach | PMMA
Datasheet:NMO-TINA3-W PDF
Manufacturer LEDiL Oy
Type: Lense
LED Series: 3535
Beam type: Wide
Beam angle: 48 °
Model: 1-fach
Type + Color of holder: Lens White
Plug-in depth: 0,8 mm
Length: 16.1 mm
Width: 16.1 mm
Heigth: 6.9 mm
Min. operating temperature: -40 °C
Max. operating temperature: 80 °C
Models: -
Merkzettel DETAILS Details
Request Anfrage
Hint: current revision of the supplier datasheet is applicable

Design-In Support

Do you have questions about the TINA-Series from LEDiL Oy or are you looking for alternatives? As an authorized distributor, we maintain a very close exchange with LEDiL Oy and are happy to advise you with our many years of experience in the selection of suitable components and possible adaptations. Please contact us!
Support

Brochures, flyers and presentations

LED System House
  PDF   | Sites: 6 | 3.5 MB
Download
Optics for LED-illumination applications
  PDF   | Sites: 8 | 3 MB
Download
LED-Modules and -Systems
  PDF   | Sites: 16 | 3 MB
